To reset AutoCAD to default settings, use one or more of the following methods: 1. Launch AutoCAD with the /clean option to clear temporary data by editing the shortcut target and adding /clean, then restart normally. 2. Use the CUI command within AutoCAD to reset toolbars, menus, or workspaces by clicking Reset in the respective tabs and restarting if needed. 3. Through the OPTIONS menu, switch to or reset the “Default” profile, though custom templates may still affect settings. 4. Manually delete or rename configuration files (like .arg, .bak) located in Autodesk’s AppData folder, which resets nearly all settings including palettes and layouts to factory defaults upon relaunch. These steps vary slightly per version but are generally effective for resolving issues.
If AutoCAD is acting strangely or you’ve messed up the settings, resetting it to default can help. It’s not complicated, but it does require a few specific steps depending on your version and what exactly needs fixing.

Resetting Through the Startup (Using /clean Option)
One of the most effective ways to reset AutoCAD is by launching it with a special command that clears some cached data and resets certain settings.

- Close AutoCAD completely.
- Right-click your desktop shortcut (or Start menu entry) for AutoCAD.
- Choose Properties.
- In the Target field, add a space and then type
/clean
at the end. - Click Apply, then Open.
This won’t reset everything — it mostly clears temporary data like program locks, partial profiles, and corrupted caches. You might need to restart AutoCAD normally afterward for changes to fully take effect.
Using the CUI Command to Reset Toolbars and Menus
If the issue is missing toolbars or messed-up menus, you can often fix it from within AutoCAD itself using the CUI (Customize User Interface) command.

- Type
CUI
in the command line and press Enter. - In the dialog that opens, click the Reset button under the Toolbars, Menus, or Workspace tabs.
- Confirm the reset when prompted.
You may need to switch workspaces or restart AutoCAD for the changes to appear properly.
Resetting via the Options Menu (Profile Reset)
AutoCAD stores settings in profiles, and you can switch or reset them through the Options menu.
- Type
OPTIONS
and go to the Profiles tab. - Select “Default” or another known working profile and click Set Current.
- If needed, click Reset to restore the selected profile to its original state.
This doesn’t always reset everything — especially if custom templates (.dwt files) are involved — so it’s good to also check your startup drawing templates.
Deleting or Renaming the Configuration File Manually
For a more aggressive reset, you can manually delete or rename AutoCAD's configuration files. These vary slightly between versions and operating systems, but they're usually found in:
C:\Users\$$YourName]\AppData\Roaming\Autodesk\AutoCAD [Version]
Look for files ending in .arg
, .bak
, or folders like AcadSystemVariableSnapshot
.
- Rename or move these files before starting AutoCAD.
- On next launch, AutoCAD will create new default files.
This method resets almost everything — including tool palettes, commands, and workspace layouts — back to factory defaults.
That’s basically how you do it. Depending on your problem, one or more of these methods should get things back on track. Some steps might vary slightly based on your AutoCAD version, but the core ideas stay the same.
