How to change text style and size in AutoCAD?
Jul 14, 2025 am 12:19 AM
The key to adjusting text styles and sizes in AutoCAD is to set the default styles and use the modification tool flexibly. First, open the "Text Style" manager, select the current style and modify the font, height and other parameters to set the default style; secondly, select the existing text and adjust the style or height through the "Properties" panel to achieve single text modification; finally, use "Quick Select" to batch select text to modify uniformly according to conditions, or replace the content with the "Find" function and adjust the style and size simultaneously to ensure that the drawing specifications are consistent.
It is actually not difficult to adjust the text style and size in AutoCAD, but many novices tend to ignore some key settings, resulting in inconsistent text display when drawing or not complying with drawing specifications. The following methods can help you adjust the appearance of your text more efficiently.
Steps to set the default text style
AutoCAD's text style is the basic setting that controls font, height, tilt angle, etc. Modifying the default style will allow the text you enter later to automatically apply a new format.
- Open the "Text Style" manager: click the "Format" menu → "Text Style", or enter the command
STYLEdirectly and press Enter. - Select the currently used style (such as STANDARD) and click "Modify".
- Select the font you need in "Font Name", such as the commonly used
txt.shxorgbcbig.shx(for Chinese). - If you want to manually specify the height every time you enter text, keep the "height" to 0; if you want to have a unified font size, fill in the specific value here, the unit is graphic unit (usually millimeters).
- Save the settings after confirmation.
After this setting, the newly entered text will use the style you defined.
Modify the size and style of existing text
If you have entered some text and want to temporarily change the font size or font, you can do this:
- Select the text object you want to modify.
- Open the Properties panel (shortcut
Ctrl 1), and find the Text Style and Height options. - If you need to change the style, select another style you already have from the drop-down menu; if you just change the font size, just enter the new height value directly.
This method is suitable for individual text fine-tuning and not for batch modification.
How to batch modify text
When you have a lot of text that needs to be adjusted uniformly, such as changing all the annotation text from 2.5 to 3.5, it is too troublesome to manually change it one by one. At this time, you can use "Quick Select" or "Find and Replace".
Use Quick Select to batch select text:
- Right-click on the drawing area → select Quick Select.
- Select "Text" for object type.
- Conditions can be filtered by "style", "height", "content", etc.
- After clicking OK, all text that meets the criteria will be selected and then modified uniformly through the "Properties" panel.
Use the Find function to locate and replace specific text:
- Enter the command
FINDEnter. - Enter what you are looking for, and you can also specify whether it is case sensitive.
- After finding the results, you can replace the text content individually or in batches, and you can also adjust their style or size by the way.
Basically these common methods are. Although it seems that there are a lot of steps, it is very quick to operate after proficiency and can make the drawings look more professional. The key is to set the style first, and then flexibly use the modification tool according to the situation.
